DK2 Elite Combat Winch 10000lb Steel Cable
Built specifically for military use, able to withstand extreme climates & temps.
Features include hardened 3 stage planetary gears for reliable and efficient use in the harshest environments.
The waterproof remote control has thermometric LED indicators signals to monitor the temperature of the motor and high temp lithium grease is used which doesnÄôt solidify in extreme climates.
California Proposition 65 Warning.Features
- IP68 Rated Military Grade Winch & Control Box.
- Hardened 3 stage planetary gears
- Waterproof remote control with LED indicators.
- Corrosion & Chemical Resistant Powder Coat
- High Temperature Lithium Grease that won't solidify in extreme temperatures
- Rated Line Pull 10000 lbs (4536 kgs) Motor 12V :4.6kW / 6.2hp 24V : 6.5kW / 8.7hp Gearing 228:1 Drum Size - Dia x L 63 x 217mm (2.48 x 8.5 in) Cable - Dia x L 9.1mm x 25m (0.35 in x 82 ft) Dimensions 574 x 16 x 259mm (22.6 x 6.3 x 10.2 in) Mounting Pattern 254 x 114.3mm 10 x 4.5 in 4-M10 Weight kg 37.5kg (82.7 lbs)
- Layer of Rope/Cable Line Pull: lbs(kgs) Rope on drum ft(m) 1 10000 (4536) 16.1 (4.9) 2 7980 (3620) 36.4 (11.1) 3 6640 (3012) 61.0 (18.6) 4 5680 (2576) 82.0 (25.0
- Line Pull lbs (kgs) Line Speed 12v ft/min (m/min) Line Speed 24v ft/min (m/min) Amp Draw 12v Amp Draw 24v 0 32.2 (9.8) 34.4 (10.5) 65 45 3000 (1361) 14.8 (4.5) 16.4 (5.0) 140 85 6000 (2722) 10.5 (3.2) 12.5 (3.8) 260 140 8000 (3629) 7.5 (2.3) 9.8 (3.0) 320 175 10000 (4536) 5.2 (1.6) 7.5 (2.3) 380 210
Specifications
Brand Name - DK2
Assembled Depth (in) - 22.6
Assembled Weight (lbs) - 82.7
Assembled Width (in) - 6.3
Assembly Required - Yes
Color - Black
Country of Origin - China
Height (in) - 10.2
MFG Part # (OEM) - T1000-100
Material - Steel
Package Contents - Elite Combat Winch 10000lb Steel Cable
Package Depth - 13.18
Package Height - 25
Package Weight - 90.39
Product Condition - New
Sound Decibels (dB) - 70 dBA
UPC - 827518007167
Warranty Type - 1 Year
